The clip-on two way soft closing hinge with cam adjustment and 3D base plate represents a standardized hardware solution for cabinet door mounting. Designed for furniture manufacturers, cabinetry producers, and commercial fit-out contractors, this hinge model k02-1 addresses common installation challenges such as door alignment adjustments, noisy door closure, and corrosion in humid environments. The clip-on mounting mechanism allows tool-free attachment and removal of the hinge arm from the base plate, which supports efficient assembly line operations and post-installation maintenance.
Constructed from iron with nickel plating, the hinge operates with a two-stage soft-closing system that controls door speed during the final phase of closure. The 3D adjustable base plate provides adjustment along three axes, enabling installers to fine-tune door position without disassembly. This feature reduces on-site adjustment time for commercial projects involving multiple cabinet units.
The cam adjustment system on the hinge arm enables lateral door positioning. Rotation of the cam screw shifts the door horizontally, allowing installers to align gaps between adjacent cabinet doors. This adjustment range accommodates common installation tolerances encountered in furniture production and commercial renovation projects.
The 3D base plate supports adjustment across height, depth, and side directions. Height adjustment accommodates variations in cabinet carcase construction, while depth adjustment controls the distance between the door and the cabinet frame. Side adjustment works in conjunction with the cam mechanism for comprehensive door alignment. Each adjustment is performed using a standard Phillips screwdriver, requiring no specialized tools.
The integrated hydraulic damper delivers two-stage closing performance. During the initial closing arc, the door moves freely under manual force. As it approaches the closed position, the damper engages and decelerates the door, preventing slamming. This mechanism operates consistently across the 50,000-cycle test rating, supporting long-term performance in high-traffic commercial installations such as office kitchens and hospitality cabinetry.
The following parameters define the dimensional and operational specifications of model k02-1. Commercial buyers may reference these values during product selection and cabinet design planning.
Cup diameter | 35mm |
Cup depth | 11.3mm |
Overlay | Full overlay / Half overlay / Inset |
Opening angle | 105 degree |
Optional door thickness | 15-20mm |
Door Dimension(K) | 3-7mm |
Use time | 50000 Times |
Color | Eletroplating Black |
Delivery time | 25-45days |
Payment term | EXW/FOB |
This clip-on hinge series suits multiple commercial procurement scenarios. Kitchen cabinet manufacturers can integrate these hinges into standard production lines, as the 35mm cup diameter matches industry-standard boring specifications. Furniture factories producing wardrobes, bathroom vanities, and storage cabinets benefit from the clip-on assembly method, which reduces per-unit installation time.
For commercial fit-out contractors working on hotels, office buildings, and residential developments, the 3D adjustment capability reduces post-installation rework. The nickel plating finish provides corrosion resistance suitable for bathroom and kitchen environments where moisture exposure occurs regularly. The three overlay options — full overlay, half overlay, and inset — accommodate different cabinet door design styles.
The hinge undergoes a 48-hour neutral salt spray test to assess corrosion resistance of the nickel plating finish. This test evaluates material performance under accelerated humid and saline conditions, providing a reference for expected service life in damp installations.
Cycle fatigue testing records 50,000 opening and closing operations under standard load conditions. This test data helps commercial buyers estimate product lifespan in different usage frequency scenarios, from low-traffic residential cabinetry to high-frequency commercial kitchen storage.
Installation requires a 35mm diameter bore hole drilled to 11.3mm depth in the cabinet door. The base plate mounts to the cabinet carcase side panel using standard screws. The clip-on design means the hinge arm attaches to the base plate by pressing until the locking mechanism engages, with no screw driving required for this step.
After initial mounting, three separate adjustment screws control door positioning. The side adjustment screw on the hinge arm handles lateral alignment, while the two screws on the 3D base plate manage height and depth adjustments respectively. All adjustments are accessible from the front with the door in closed position.
This hinge model is designed for door thickness between 15mm and 20mm. Doors outside this range may require alternative hinge models or custom mounting plates.
The hydraulic damper is integrated into the hinge body and operates automatically during each closing cycle. It cannot be manually deactivated.
Bulk ordering options are available for furniture manufacturing and construction projects. Specific MOQ details and volume pricing are provided through direct inquiry.
The standard finish is nickel plating with electroplating black option. Custom finish requests for large volume orders can be discussed during the quotation process.
Standard delivery time ranges from 25 to 45 days depending on order volume and current production schedule. Expedited production may be available for time-sensitive commercial projects upon request.
